Model:LT18-1 |
|||
|
Engine |
Kubota Engine D722,Koop Engine 292 |
Min.ground clearance |
119mm |
|
Mainvalve |
BEIFANG |
Tail turning radius |
790mm |
|
Working weight(kg) |
1800kg |
Track ground length |
1050mm |
|
Bucket capacity |
0.03m3 |
Track length |
1545mm |
|
Power |
10.2kw/14kw |
Max digging height
|
2580mm
|
|
Swing speed
|
12RMP
|
Max.unloading height
|
1637mm
|
|
Gradeability
|
30
|
Max.digging depth
|
2060mm
|
|
Overall legnth
|
4325/1655mm
|
Max.digging distance
|
3160mm
|
|
Overall width
|
1100mm
|
Min.turning radiuse
|
1711mm
|
|
Upper width
|
990mm
|
Max.height at minimum
turning radius
|
2048mm
|
|
Overall height
|
2272mm
|
||
|
Standard track shoe width
|
180mm
|
Boom swing Angle(left)°
|
75
|
|
Track Gauge
|
920mm
|
Boom swing Angle(right)°
|
45
|
