| Model | CPD-15 |
| Rated lifting weight | 1500kg |
| Load center distance | 500mm |
| Dynamic way | battery |
| Driving way | Car type |
| The wheelbase | 1480mm |
| Tire type | Elastic solid tire |
| Number of wheels (front/rear) | 2/2 |
| Before the wheel track | 1050mm |
| After the wheel track | 950mm |
| Height of door frame when retracting | 2150mm |
| Maximum lifting height | 3000mm |
| Maximum height during operation | 4100mm |
| Height of roof guard | 2020mm |
| The goods fork length | 1220mm |
| Body length (excluding fork) | 2100mm |
| Body width | 1200mm |
| Turning radius | 2250mm |
| Minimum ground clearance | 150mm |
| The whole weight of | 2100kg |
| Drive motor | 4.0KW |
| The oil pump motor | 3.0KW |
| Drive motor control mode | AC |
| Oil pump motor control mode | AC |
| Turned to the way | Hydraulic booster |
